Home » Conductive Platinum Paste (Pt, Purity: 99.9%, APS: 80-100nm)

CONDUCTIVE INK / PASTE

Stock No. CAS MSDS Specification COA
NS6130-10-1307 7440-06-4 Specification pdf COA pdf

Conductive Platinum Paste (Pt, Purity: 99.9%, APS: 80-100nm)

Conductive Platinum Paste

Product: Conductive Platinum Paste (Pt, Purity: 99.9%, APS: 80-100nm)

Quality Control: Each lot of NANOSHEL Conductive Platinum Paste was tested successfully.


Product Conductive Platinum Paste
Stock No NS6130-10-1307
CAS 7440-06-4 Confirm
APS 80-100nm Confirm
Purity 99.9% Confirm
Molecular Formula Pt Confirm
Molecular Weight 195.08 g/mol Confirm
Form Paste Confirm
Color Grey Confirm
Melting Point 1772 °C Confirm
Boiling Point 3827 °C Confirm
Density 21.45 g/cm³ Confirm
Viscosity 2500-4500 mPa Confirm
Storage temp. 2-8 °C Confirm
Paste Data .
Rheology Thixotropic, Screen Printable Pastes Confirm
Viscosity 315±100 Pa:S (Brookfield Hbt) Confirm
Shelf Life 6 Months Confirm
Processing .
Screen Mesh/Emuslion 200-325 Mesh/5 µm Confirm
Peak Firing Temperature 1350 ± 10°C Confirm
Time at Peak 30 Minutes Confirm
Typical Properties .
Resistivity ≤ 20 Mᾨ/Sq Confirm
Adhesion ≥ 12 N Confirm
Substrate of Calibration 96% Alumina Confirm
Thinner Standard LR Grade Confirm
Main Inspect Verifier Manager QC

Typical Chemical Analysis

Assay 99.9%

Expert Reviews

Dr. Nicholaos G. Demas
Dr. Nicholaos G. Demas, (Newcastle University School Of Machanical & Systems Engg. UK)

Carbon inks/paste is lubricious, providing low friction and excellent thermal stability. They are also chemically inert, with low reactivity to solvents and other chemicals. The carbon inks can be applied by screen-printing, dipping, and syringe dispensing and feature excellent adhesion to Kapton, Mylar, glass and a variety of other substrates. Unlike conventional conductive materials, carbon inks are very resistant to abrasion, scratching, flexing and creasing.


Dr. Ms. Kamiko Chang, Ph.D
Dr. Ms. Kamiko Chang, Ph.D, (University of Science and Technology Beijing, China)

In addition to the printed circuit board technology, carbon-conductive inks/paste is also employed in other sectors of electronics/electrical engineering. By means of carbon-conductive inks, static electricity can be discharged from plastic components and other insulators, such as paint coatings. This application is mainly used in the housing industry (television and computer housings) with the paint being relatively fluid and sheet-sprayed onto the components.


Jules L. Routbort
Jules L. Routbort, (Argonne National Laboratory, Argonne, USA)

Nano Dimension’s ink scientists can reliably extract 10-100 nanometer-sized particles of pure silver. Because of smaller particles size 10-20nm and low processing temperature 100-170 Degree C it is widely used in various printed technology. The smaller sizes of nanoparticles make the ink suitable for printing on various substrates using inkjet printing technology. This allows us to achieve the highest ink performance optimization in properties such as conductivity, adhesion and flexibility, in a wide range of applications including RFID and OLED, from the particle level all the way through formulation to the printing process itself.


Takeo Oku
Takeo Oku, (Department of Materials Science, The University of Shiga Prefecture, Hassaka 2500, Hikone, Shiga 522-8533, Japan)

Carbon ink/paste play an increasing role in applications including printed resistors, polymer thick film circuitry, membrane switches, electrical attachments, heaters, and static elimination. We can configure carbon inks to obtain a range of electrical conductivity values by blending them with silver inks and adjust conductivity to a specific level. Nanoshel can also blend carbon inks with silver inks to reduce cost for some applications.


Dr. Ms. Guixin (Susan), Ph.D
Dr. Ms. Guixin (Susan), Ph.D, (Switzerland-Institute for Inorganic Chemistry, Zurich, Switzerland)

Conductive inks/paste is used to substitute gold, manufacture resistors, cross-over conductors, shielding surfaces and in place of discrete resistors, etc. In addition to the printed circuit board technology, carbon-conductive inks are also employed in other sectors of electronics/electrical engineering. By means of carbon-conductive inks, static electricity can be discharged from plastic components and other insulators, such as paint coatings. This application is mainly used in the housing industry (television and computer housings) with the paint being relatively fluid and sheet-sprayed onto the components.
