Home » Copper Foil Sheet Roll (Cu, Purity: >99.8%, APS: 10?m)

METAL FOILS

Stock No. CAS MSDS Specification COA
NS6130-12-000330 7440-50-8 MSDS pdf Specification pdf COA pdf

Copper Foil Sheet Roll (Cu, Purity: >99.8%, APS: 10?m)

Copper Foil Sheet Roll

Copper Foil Sheet Roll (Cu, Purity: >99.8%, APS: 10?m)

Quality Control: Each lot of Copper Foil was tested successfully.

Copper Foil Sheet Roll

Copper Foil Sheet Roll


Product Copper Foil
Stock No NS6130-12-000330
CAS 7440-50-8 Confirm
Purity ≥99.8% Confirm
Thickness 10μm (8μm, 9μm, 12μm, 15μm, 20μm) Confirm
Tensile Strength ≥25 Kg/mm² Confirm
Surface density 95-100g/m² Confirm
Extensibility ≥2.5% Confirm
Roughness Rz ≤3.0μm Confirm
Thickness tolerance -0, +3 Confirm
Width tolerance ±1 Confirm
Tolerance oxidation susceptibility 160℃/10min.no oxidation Confirm
Joint 1Pcs/roll Confirm
Roll weight Consulted By Supplier and Acquire Confirm
Polished Both Side Polished Confirm
Coarse 8μm, 9μm, 12μm, 15μm, 20μm Confirm
Rohs requirement Pass Confirm
Appearance quality convex No oxidation, Smooth and no concave-convex
Storage requirement Temperature: 25°C, Humidity:≤60 %RH There are no corrosive gas and material, Moist material.
Main Inspect Verifier Manager QC

Expert Reviews

Dr. Baron Augustin, Ph.D
Dr. Baron Augustin, Ph.D , (TUM)(Technical University of Munich, Germany)

Metal- Foil based nanotechnology could enable large scale production of lighter, cheaper, and environmentally friendly deep UV LED. Metal foils attract a large field of applications, e.g. in micro-technology they are being used for sensors, actors, micro-electro-mechanical systems and in medical devices. Stainless steels, FeNi alloys, Nickel and Nickel based alloys, Copper as well Aluminium are the principal materials for our metal foils.


Dr. Darren Chandler, Ph.D
Dr. Darren Chandler, Ph.D, (Manchester Metropolitan University, U.K)

A foil is a very thin sheet of metal, usually made by hammering or rolling. Foils are most easily made with malleable metals, such as aluminium, copper, tin, and gold. Characteristics of metal-foils include- high permeability, low coercivity, specific electrical resistance, corrosion resistance, linear coefficient of thermal expansion, etc.


Dr. Ms. Cristiana Barzetti
Dr. Ms. Cristiana Barzetti , (University of Cagliari-Department of Chemical Engineering and Material Science, Italy)

Foils usually bend under their own weight and can be torn easily. The more malleable a metal, the thinner foil can be made with it. Foil is commonly used in household applications. It is also useful in survival situations, because the reflective surface reduces the degree of hypothermia caused by thermal radiation.
