Germanium Wafers Phosphorus Doped
(Ge, Purity: 99.9%, Dia: 4”)
| Product | Germanium Wafers Phosphorus Doped | |
| Stock No | NS6130-12-001332 | |
| CAS | 7440-56-4 | Confirm |
| Purity | 99.9% | Confirm |
| Diameter | 4” | Confirm |
| Dopant | Phosphorus | Confirm |
| Crystal Orientation | <100> | Confirm |
| Molecular Formula | Ge | Confirm |
| Molecular Weight | 72.61g/mol | Confirm |
| Surface | Polished both side | Confirm |
| Resistivity | 0.3-1ohmcm | Confirm |
| Quality Control | Each lot of Germanium Wafers Phosphorus Doped was tested successfully. | |
| Main Inspect Verifier | Manager QC | |
Typical Chemical Analysis
| Assay | 99.9% |
| Other Metal | 750ppm |
