Graphene Nanoplatelets (C, Purity: 99.5%,Thickness: 2-4nm)

Graphene Nanoplatelets

Product: Graphene Nanoplatelets (C, Purity: 99.5%,Thickness: 2-4nm)

Quality Control: Each lot of NANOSHEL Graphene Nanoplatelets was tested successfully.

Product Name Graphene Nanoplatelets
Stock No. NS6130-12-000298
CAS 7782-42-5 Confirm
Purity 99.5 % (Metal base) Confirm
Thickness 2-4nm Confirm
Layer Flake 4-6layers (50-80%) Confirm
Colour Black Confirm
Lattice Defects Low to medium concentration Confirm
SSA 20-40 m2/g Confirm
Lateral Size ~5µm (± 3%) Confirm
pH 6-7 Confirm
Ash <0.5% Confirm
Morphology Flaky Confirm
Bulk Density ~ 0.10 g/ml Confirm
True Density ~ 2.3 g/cm3 Confirm
Electrical Conductivity 80000 S/m Confirm
Tensile Strength 5 Gpa Confirm
Impurities < 0.1%, H2O~0.02% (quartz + mica)
Main Inspect Verifier Manager QC

 Experts Review:

Miller-(Christopher)-345x239Dr. Baron Augustin, Ph.D (TUM)(Technical University of Munich, Germany)
Graphene Nanoplatelets consist of small stacks of graphene that can replace carbon fiber, carbon nanotubes, nano-clays, or other compounds in many composite applications. When they are added at 2-5wt% to plastics or resins they make these materials electrically or thermally conductive and less permeable to gasses, while simultaneously improving mechanical properties like strength, stiffness, or surface toughness.


images (33)

Dr. Darren Chandler, Ph.D(Manchester Metropolitan University, U.K)
Graphene nanoplatelets, which combine the layered structure and low price of nanoclays with the superior mechanical, electrical, and thermal properties of carbon nanotubes, are very cost-effective, and can simultaneously provide a multitude of physical and chemical property enhancements.


Wiggs

Dr. Ms. Cristiana Barzetti (University of Cagliari-Department of Chemical Engineering and Material Science, Italy)
Graphene Nanoplatelets particles consist of small stacks of graphene obtained by exfoliation of expanded Graphene. The size and morphology of nanoplatelets makes these particles especially effective at providing barrier properties, while their graphene structure makes them excellent thermal and electrical conductors. Unlike many other additives, Graphene nanoplateletes improve mechanical properties like stiffness, strength, and surface hardness of the matrix material.


jetsonlee

Dr. Jang Huang, Ph.D (Shandong Science and Technology University, China)
Graphene nanoplatelets improves mechanical properties of most composites, particularly stiffness and tensile strength. Elastomeric compounds have been shown to experience increased life and reduced surface wear when reinforced with Graphene nanoplatelets. Particles can be aligned using electric field, although alignment is not necessary for use in most extrusion systems.


images (21)Dr. Mark Brown (Georgia Institute of Technology in Atlanta,USA)
Graphene nanoplatelets can also be combined with glass fibers or other matrix materials to provide sufficient conductivity for electrostatic painting or other applications requiring electrical conductivity. Graphene nanoplatelets has a percolation threshold for conductivity of 1.9 wt% in thermoplastic matrix. At densities of 2–5 wt%, conductivity reaches sufficient levels to provide electromagnetic shielding.


Graphene Nanoplatelets

Graphene Nanoplatelets
