Lithium Ion Battery Material

Stock No.

NS6130-12-001721

CAS

346417-97-8

MSDS

Specifications

COA

Catalogue

Lithium Nickel Cobalt Manganese Oxide NCM111 Li

Ni0.33Co0.33Mn0.33

Lithium Nickel Cobalt Manganese Oxide NCM111

Available Pack Size: 10Gms, 25Gms, 50Gms, 100Gms, 250Gms, 500Gms, 1Kg & Bulk orders

Preview

SEM - NCM111

Preview

XRD - NCM111

Preview

Particles Size Analysis

Product	Lithium Nickel Cobalt Manganese Oxide NCM111
Stock No	NS6130-12-001721
CAS	346417-97-8
Purity	99.9%
APS	10microns
Molecular Formula	Li(Ni0.33Co0.33Mn0.33)O2)
Appearance	Black Powder
Melting Point	290 °C (>554 °F) – lit.
Boilling Point	1342 °C (2448 °F) – lit.
Cycle Life	1000–2000
Flash Point	26.1°C (79.0 °F)
Voltages	3.60V, 3.70V nominal; typical operating range 3.0– 4.2V/cell, or higher
Specific energy (Capacity)	150–220Wh/kg
Charge (C-Rate)	0.7–1C, charges to 4.20V, some go to 4.30V; 3h Charge Typical. Charge current above 1C shortens Battery life.
Discharge (C-Rate)	2.50V cut-off
Thermal Runaway	210°C (410°F) typical. High charge Promotes thermal runaway
Application	E-bikes, medical devices, EVs, industrial
Quality Control	Each Lot of was tested successfully
Main Inspect Verifier	Manager QC

Typical Chemical Analysis

Lithium %	7.8%
Ni+Mn+Co	57.17%
Impurities	.
Fe	<100ppm
Na	<100ppm
Cu	<50ppm
pH	10.7
Moisture	350ppm
BET Surface Area	0.55 m2/g
Tap Density	2.2 g/cm3
1st Discharge Capacity	155-158 mAH/g
1st Efficiency	83-85%

Expert Reviews

Lithium Nickel Cobalt Manganese Oxide NCM111

Contact Us:

From us, you can easily purchase Lithium Nickel Cobalt Manganese Oxide NCM111 Li(Ni0.33Co0.33Mn0.33)O2), Purity: 99.9%, APS: 10microns) at great prices. Place an online order and we will dispatch your order through DHL, FedEx, UPS. You can also request a quote by mailing us at sales@nanoshel.com. We invite you to contact us for further information about our company and our capabilities. At Nanoshel, we look forward to your suggestions and feedback.
