Meso Carbon Microbeads (MCMB, Purity: 99.9%, APS: 18-20µm)

Meso Carbon Microbeads

Product: Meso Carbon Microbeads (Purity: 99.9%, APS: 18-20µm)

Quality Control: Each lot of Meso Carbon Microbeads was tested successfully.

Meso Carbon Microbeads

Particles Size Analysis

Materials Meso Carbon Microbeads
Stock No NS6130-12-000321
CAS 7782-42-5 Confirm
Purity 99.9% Confirm
APS 18-20µm Confirm
Molecular Formula C Confirm
Molecular Weight 12.01g/mol Confirm
Appearance Black powder Confirm
Melting Point 3550 °C Confirm
Boiling Point 4027 °C Confirm
Specific Surface Area 2.022 m2/g Confirm
First Discharge Capacity 345.2 mAh/g Confirm
Solubility Insoluble in water
Application MCMB Graphite Powder for Li-ion Battery Electrodes
Main Inspect Verifier Manager QC

Experts Review:

58496396Dr. Bruce Perrault, Ph.D (Georgia Institute of Technology (Georgia Tech), USA)
Meso Carbon Microbeads
High-density carbon materials play a key role in various high-temperature applications due to their mechanical properties and a unique combination of other characteristics. Mesocarbon microbead(MCMB) has been explored by many researchers as an excellent precursor for high-density carbon materials with attractive advantages.

1252525Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)
Meso Carbon Microbeads
composites are successfully fabricated by optimized hot-press sintering and further carbonization. They exhibit a higher apparent density and lower open porosity than those of the cold-pressed composites, although their strength is slightly inferior to the latter.

2536582Dr. Huojin Chan (University of Science and Technology of China, Hefei, Anhui, China)
Meso Carbon Microbeads,
The outer graphitic shells of the porous carbon microbeads contribute to a conductive network which will remarkably facilitate the electron transportation, and thus can be used to construct a high-rate, high-capacity cathode for hybrid supercapacitor, especially at high current densities.

10604509_1459864657612760_2405225879143508610_oDr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
Meso Carbon Microbeads
The charge‐discharge reaction mechanism of the graphitized mesocarbon microbead (MCMB) anode was investigated with cyclic voltammetry and x‐ray diffractometry. It is concluded that the charge‐discharge reaction of graphitized MCMB involves intercalation of lithium, which is essentially similar to that for graphite.

Meso Carbon Microbeads

Meso Carbon Microbeads
