Nanoclay Montmorillonite 20A (Purity: 99%, APS: <80nm)

Nanoclay Montmorillonite 20A

Product: Nanoclay Montmorillonite 20A (Purity: 99%, APS: <80nm)

nanoclay montmorillonite 20A  is an additive for plastic to improve various plastic physical properties, such as reinforcement, HDT, CLTE and barrier. (Organic Modifier 2M2HT: Dimethly, Dehydrogenated tallow, Quaternary ammonium)

Nanoclay Montmorillonite 20A

Particles Size Analysis – Nanoclay Montmorillonite 20A

Product Nanoclay Montmorillonite 20A
Stock No NS6130-09-933
APS <80nm Confirm
Purity 99% Confirm
Molecular Formula Al2O34SiO2H2O Confirm
Molecular Weight 202.185 g/mol Confirm
Color Light cream/off white Confirm
Uncompacted Density 47.5 lbs./cu.ft. Confirm
Alumina Silicate Layers ~ 1nm thick Confirm
Compacted Bulk Density 37 to 56 lbs./ft3 Confirm
Specific Gravity 2.6 Confirm
Organic Modifier 2MBHT Confirm
pH 8.5 to 10.5 Confirm
Modifier Concentration 95 meq/100g Clay Confirm
Solubility Soluble in water, Ethanol
Main Inspect Verifier Manager QC (Nanoclay Montmorillonite 20A)

 Experts Review:

101Dr. jim Duncan, Ph.D (Norwegian University of Science and Technology Trondheim, Norway)
Nanoclays are nanoparticles of layered mineral silicates.  Depending on chemical composition and nanoparticle morphology, nanoclays are organized into several classes such as Montmorillonite, Bentonite, Kaolinite, Hectorite, and Halloysite. Clay minerals are hydrous silicates and may simply be described as fine-grained particles with sheet like structure stacked over one another.


102Dr. Mauritz Backman, Ph.D (Technical University of Lisbon (UTL), Portugal)
Nanoclay is used in ink formulation. It helps to adjust the consistency of printing inks to the desired value, avoiding pigment sedimentation, providing good colour distribution, obtaining desired film thickness etc. by incorporation of small amount of organically modified layered silicate. The performance of cosmetics is enhanced by use of nanoclay and they allows good colour renention for lipsticks, eye shadows and nail lacquers.


103Dr. Lounis Madani (University of Abou Bekr Belkaïd, Algeria)
The nanometer sized Montmorillonite clay particles can improve surface integrity and provide advantages in the mechanical and thermal properties of the composites. The interaction between nanoclay and surrounding matrix even though high tensile strength and modulus were obtained.


104Dr. Eric Lin, Ph.D (Sukhothai Thammathirat Open University (STOU) Nonthaburi,Thailand)
The use of nanoclays in water waste treatment has become common in industry today. Nanoclay exhibit a synergistic effect with many commonly utilized water treatment unit processes  including granular activated charcoal, reverse osmosis and air strippers. Granular activated carbon is particularly effective at removing a large range of organic molecules from water. Nanoclay have proven to be the technology of choice for treating oily wastewaters.


105Dr. Robert Wing, Jr. (University of British Columbia, Canada)
Nanoclay as drug vehicle:  Nanoclay as drug vehicle for controlled release of drug is one of the born age area in medical application, nanoclay have great potential as compared to polymer and carbon nano tubes for drug delivery applications.


Nanoclay Montmorillonite 20A

Nanoclay Montmorillonite 20A
