Shape Memory Polymer Resin (Potting)

Shape Memory Polymer Resin

Product: Shape Memory Polymer Resin

Quality Control: Each lot of NANOSHEL Shape Memory Polymer Resin (Potting) was tested successfully.



Index Material Shape Memory Polymer Resin Packing unit
PMM Pellet Injection・Extrusion 20Kg Bag
PMP Shape Memory Polymer Resin Potting 2Kg Can×2
Physical Form Pellets (Injection Moulding Capability)
Shape Memory Polymer Resin Glass Transition temp 65°C
Shape Memory Polymer Resin Metlting Temp 200°C
Shape Memory Polymer Resin Specific Gravity 1.25
Shape Memory Polymer Resin Temperature Stability 300°C
Shape Memory Polymer Resin Tensile Strength ~13Mpa (Rubber Region)
Shape Memory Polymer Resin Elongation >600%
Shape Memory Polymer Resin Bending Modulus 1900 (Glassy Region)
Shape Memory Polymer Resin Bending Strength 50MPa (Glassy Region)
Potting Type (PMP)
Colour Tone Light Yellow
A/B Weight Ratio 40/60
Viscosity Sol A 360
Viscosity Sol B 300
Specific Gravity Sol A 1.062
Specific Gravity Sol B 1.215
Strength G/R
Bending Strength (MPa) 75
Bending Modulus(MPa) 1800
Tensile Strength(MPa) 52
Elongation(%) 10-30
Hardness(Shore D) 80
Strength R/R
Tensile Modulus(MPa) 20
Tensile Strength(MPa) >400
Elongation(%) 4.5
Hardness(Shore D) 40
Glass Transition Point(℃) 55°C
Cure
Pot Life (Standard) 180Sec
Cure Temp (℃×time) 70°C for 1-2Hours

Experts Review:

101Dr. jim Duncan, Ph.D (Norwegian University of Science and Technology Trondheim, Norway)
Polymer nanocomposites consist of polymer  or copolymer having nanoparticles or nanofillers dispersed in polymer matrix. These may be of different shapes (fibers, platelets, spheroids) but atleast one dimension must be in range 1-50nm. Polymers are light weight  and corrosion resistant materials.


102Dr. Mauritz Backman, Ph.D (Technical University of Lisbon (UTL), Portugal)
Furthermore, polymers are versatile materials for nanotechnology due to their processability, flexibility, diverse functionalities, low cost and tunable properties. They have high thermal, electrical and mechanical properties characteristics.


103Dr. Lounis Madani (University of Abou Bekr Belkaïd, Algeria)
Polymer Nanomaterials has revealed the property advantages that nanomaterial additives can provide in comparison to both their conventional filler counterparts and base polymer. Properties which have been shown to undergo substantial improvements include: (1) Mechanicals e.g. strength, modulus and dimensional stability (2) Improved solvent and heat resistance (3) Decreased permeability to gases, water and hydrocarbons (4) Thermal stability and heat distortion temperature (5) Flame retardancy (6) Chemical resistance (7) Surface appearance (8) Electrical conductivity (9) Optical clarity in comparison to conventionally filled polymers.


104Dr. Eric Lin, Ph.D (Sukhothai Thammathirat Open University (STOU) Nonthaburi,Thailand)
The utility of polymer-based nanomaterials in these areas is quite diverse involving many potential applications and have been proposed for their use in various applications. They are used in memory devices, bio-imaging, drug delivery, chemical sensors, electroluminescent devices, electro catalysis, batteries, smart windows, electromagnetic interference shielding, transparent conductive coating, electrostatic dissipation, photovoltaic, gas sensors, optical displays, superconductor devices etc


105Dr. Robert Wing, Jr. (University of British Columbia, Canada)
Conjugation of polymers with various nanoscale filler inclusions have been used for sensor applications including gas sensors, biosensors and chemical sensors. The nanofillers employed include metal oxide nanowires, carbon nanotubes, nanoscale gold, silver, nickel, copper, platinum and palladium particles. Polymer-based solar cells have the capability of being used to make cheap large flexible panels.
