Silicon Carbide Wafer N Types
Silicon Carbide Wafer N Types (2", Nitrogen Doped)
Silicon Carbide Wafer N Types
| Product | Silicon Carbide Wafer N Type | |
| Stock No | NS6130-10-1156 | |
| Diameter | 2” | Confirm |
| Thickness | 430±25µm | Confirm |
| Dopant | Nitrogen | Confirm |
| Type | N | Confirm |
| Resistivity | 0.012-0.0028Ω.Cm | Confirm |
| Secondary flat length | (8 ± 1.7) mm | Confirm |
| Primary flat length | (16 ± 1.7) mm | Confirm |
| Primary flat orientation | Parallel {1-100} ± 5° | Confirm |
| FWHM | A<30 arcsec | Confirm |
| Surface | <0.5 nm | Confirm |
| Molecular Formula | SiC | Confirm |
| Surface Finish | Single or double face polished | Confirm |
| Quality Control | Each lot of Silicon Carbide Wafer N Type was tested successfully. | |
| Main Inspect Verifier | Manager QC | |
