Home » Silicon Substrate (Si, p-Type, Orientation: <111>, Diameter: 2")
SINGLE CRYSTAL SUBSTRATES
| Stock No. | CAS | MSDS | Specification | COA |
|---|---|---|---|---|
| NS6130-10-1421 | 7440-21-3 |
|
|
Silicon Substrate
(Si, p-Type, Orientation: <111>, Diameter: 2")
| Product | Silicon Substrate | |
| Stock No | NS6130-10-1421 | |
| CAS | 7440-21-3 | Confirm |
| Diameter | 2" | Confirm |
| Thickness | 275µm | Confirm |
| Molecular Formula | Si | Confirm |
| Type | p-Type | Confirm |
| Form | Solid | Confirm |
| Orientation | <111> | Confirm |
| Resistivity | 0.001 ~ 10000 ohm-cm | Confirm |
| Polished | One side polished | Confirm |
| Bow / Warp | ≤ 40µm | Confirm |
| TTV | ≤ 10µm | Confirm |
| Quality Control | Each lot of Silicon Substrate was tested successfully. | |
| Main Inspect Verifier | Manager QC | |
Expert Reviews
Dr. Ms. Teresa B. , (University of San Carlos, Philippines)
Single Crystal substrates has a unique combination of physical, chemical and optical properties allowing it to withstand high temperatures, high pressures, thermal stock and water or soil erosion. It is chemically inert with a low friction coefficient and excellent electrical, optical and dielectric characteristics.
Dr. Stew Dean Ph.D , (University of Technology Sydney, Australia)
Single crystal substrateshas been widely used as substrate material for the deposition of high quality oxide thin films, including semiconducting, superconducting, dielectric, ferroelectric, and ferromagnetic oxides. The quality of the oxide films is strongly correlated to the quality of the substrate.
Dr. Ms. Yi Yen Shi,, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
The anistropicproperties of crystals depends on the orientation of crystals and lead to a wide range of applications in research and development. Crystal substrates has hexagonal/rhombohedral structure. For epitaxial growth of films, different orientations will offer a range of lattice constants to match the epi material.
Dr. Myron Rubenstein,, Ph.D (Polytechnic University of Turin, Italy)
Single crystal substrates are of three types: C-plane, A-plane, R-plane. C-plane substrates are used to grow III-V and II-VI compounds such as GaN for blue LED and laser diodes. A-plane substrate provide a uniform dielectric constant and high insulation for hybrid microelectronics applications. R-plane substrates are used for the hetero-epitaxial deposition of silicon for microelectronic IC applications.
Silicon Substrate
From us, you can easily purchase Silicon Substrate at great prices. Place online order and we will dispatch your order through DHL, FedEx, UPS. You can also request for a quote by mailing us at sales@nanoshel.com. We invite you to contact us for further information about our company and our capabilities. At Nanoshel, we could be glad to be of service to you. We look forward to your suggestions and feedback.
