Silver Nanoparticle Ink (Ag, 99.9%, APS 30-100nm)

Silver Nanoparticle Ink

Product: Silver Nanoparticle Ink (Ag, 99.9%, APS 30-100nm)

Quality Control: Each lot of NANOSHEL Silver Nanoparticle Ink was tested successfully.

Product Name Silver Nanoparticle Ink
Stock No. NS6130-10-1301
CAS 7440-22-4 Confirm
APS 30-100nm Confirm
Purity 99.9% Confirm
Molecular Formula Ag Confirm
Molecular Weight 107.87 g/mol Confirm
Appearance Dispersion Confirm
Density 1.22 g/mL at 25 °C Confirm
Boiling Point 2162 °C Confirm
Resistivity 50 mΩ/sq Confirm
Surface Tension 28-32 dyne Confirm
Viscosity 8-12Cp Confirm
Storage Temp 2-8°C Confirm
Thermal Expansion (25 °C) 18.9 µm•m-1•K-1 Confirm
Poisson Ratio 0.37 Confirm
Vickers Hardness 251 MPa Confirm
Young’s Modulus 83 GPa Confirm
Solvent Water Based or Organic Confirm
Main Inspect Verifier Manager QC

Experts Review:

Miller-(Christopher)-345x239Dr. Baron Augustin, Ph.D (TUM) (Technical University of Munich, Germany)
Nano Dimension has developed a suite of conductive inks to meet the advanced needs of the electronics community. Silver nanoparticle (NP)-based inks represent the most important commercial nanotechnology-derived product and the most widely studied worldwide because it is a noble metal, featuring undisputed advantages in terms of electrical conductivity, resistance to oxidation, and providing interesting plasmonic and antibacterial properties.


images (33)

Dr. Darren Chandler, Ph.D (Manchester Metropolitan University, U.K)
Nano dimensions provides conductive inks specifically tailored for use in a wide range of applications including radio frequency identification (RFID) and OLED, from the particle level all the way through formulation to the printing process itself.


Wiggs

Dr. Ms. Cristiana Barzetti (University of Cagliari-Department of Chemical Engineering and Material Science, Italy)
Among metal nanostructures, Ag-based ones are the most diffused from both an academic and commercial point of view. This leads to the formulation of a wide range of nanostructured inks for a huge range of applications. Such inks are mainly employed in the field of printed electronics, promising to bring to the consumer great breakthroughs and unique products, shifting the usual paradigm of electronic devices and circuit boards and allowing the realization of flexible functional thin layers.


jetsonlee

Dr. Jang Huang, Ph.D (Shandong Science and Technology University, China)
Printing technology has expanded its horizon towards the realization of electron devices on any substrate, according to 2 main approaches: (1) Analog Printing (involving microstructured inks) (2) Digital Printing (involving nanostructured inks.)


images (21)Dr. Mark Brown (Georgia Institute of Technology in Atlanta,USA)
Conductive inks normally are aqueous or organic solvent dispersions of silver nanoparticles that are stabilized by surfactants and polymers that undergo printing, drying and sintering process.


Silver Nanoparticle Ink

Ag Nanoparticle Ink
