Home » SWCNT COOH (>98wt% OD:1-2nm Length:3-8µm COOH:2-4Wt%)


Stock No. CAS MSDS Specification COA
NS6130-06-619 308068-56-6 Specification pdf COA pdf

SWCNT COOH (>98wt% OD:1-2nm Length:3-8µm COOH:2-4Wt%)

SWCNT COOH Functionalized

Product: SWCNT COOH (>98wt% OD:1-2nm Length:3-8µm COOH:2-4Wt%)

Quality Control: Each lot of SWCNT COOH was tested successfully.

FTIR Spectra of Carboxylated SWCNT

FTIR Spectra of Carboxylated SWCNT

XPS Spectra of Carboxylated SWCNT

XPS Spectra of Carboxylated SWCNT

Stock No NS6130-06-619
CAS No 308068-56-6 Confirm
Category SC-SL-1 Confirm
Avg. Diameter 1-2nm Confirm
Length 3-8μm Confirm
Purity >95% (SWNT) Confirm
Amorphous carbon <3% Confirm
Residue ( calcination in air) <2% Confirm
COOH Surface Modified 2 - 5wt% Confirm
Special Surface Area 350-450* m²/g Confirm
Bulk density 0.05-0.17 g/cm³ Confirm
Real density 2-3 g/cm³ Confirm
Charging * 2180 (Capacity: mA h/g) Confirm
Discharging* 534 (Capacity: mA h/g) Confirm
Volume Resistivity 0.1-0.15 Ω.cm ( measured at pressure in powder) Confirm
Available Quantities 2Gms, 5Gms, 10Gms, 25Gms and larger quantites
Main Inspect Verifier Manager QC

Expert Reviews

Dr. Changsik Yoo, Ph.D
Dr. Changsik Yoo, Ph.D, (Nanyang Technological University, Singapore)

Pristine carbon nanotubes (CNTs) are insoluble in many liquids such as water, polymer resins, and most solvents. This means they are difficult to evenly disperse in a liquid matrix such as epoxies and other polymers, complicating efforts to utilize CNTs’ outstanding physical properties in the manufacture of nanocomposite materials, as well as in other practical nanotechnology applications which require preparation of uniform mixtures of CNTs with many different organic, inorganic, and polymeric materials.

Dr. Bram van Andel, Ph.D
Dr. Bram van Andel, Ph.D, (International Medical and Technological University, Dar es Salaam, Tanzania)

To make nanotubes more easily dispersible in liquids, it is necessary to physically or chemically attach certain molecules, or functional groups, to their sidewalls without significantly changing the nanotubes’ desirable properties. This process is called functionalization.

Dr. Ana D. Gavrilovici
Dr. Ana D. Gavrilovici, (University of Santiago of Chile (USACH), Chile)

Single-walled CNTs arguably are the ultimate biosensor among nanoscale semiconducting materials not only for their size – which is directly comparable to the size of single biomolecules – but also because their low charge-carrier density is directly comparable to the surface charge density of proteins. Furthermore, a single-walled CNT (SWCNT) consists solely of surface such that every single carbon atom is in direct contact with the environment, allowing optimal interaction with nearby biomolecules..

Dr. Yeng-Tim Liu
Dr. Yeng-Tim Liu, (National Taiwan University of Science and Technology, Taiwan)

Generally, the smart functionalization of CNTs with chemically, biochemically, or electrochemically functional materials could provide a straightforward approach to the development of nanostructured electrochemical devices with promising properties and striking applications.

Dr. Sheng Choy Wong Ph.D
Dr. Sheng Choy Wong Ph.D, (University of the Philippines College of Engineering, Quezon City, Philippines)

The strategies for the functionalization of the CNTs have strongly relied on the interactions inherent to the CNTs and the materials, which are mainly dependent on the structural and chemical properties of the materials.
