Tin Oxide Nanopowder (SnO2, F Doped, 99.9%, 80-100nm)

Tin Oxide Nanopowder

Product: Tin Oxide Nanopowder (SnO2, F Doped, 99.9%, 80-100nm)

Quality Control: Each lot of NANOSHEL Tin Oxide Nanopowder (one of the best gas sensing material) was tested successfully.

Tin Oxide Nanopowder

TEM – F-doped SnO2 Nanoparticles

F Doped SnO2 Nanoparticles

F-doped Tin Oxide Nanopowder

Material Tin Oxide Nanopowder
Stock No NS6130-03-393
CAS 18282-10-5 Confirm
APS 80-100nm Confirm
Purity 99.9% Confirm
Molecular Formula SnO2 Confirm
Molecular Weight 150.71g/mol Confirm
Doping Fluorine Doped Confirm
Doping %age 2-3Wt% Confirm
Color White Confirm
Morphology Spherical Confirm
Density 6.95 g/cm³ Confirm
Melting Point 1630 °C Confirm
Boiling Point 1800-1900 °C Confirm
SSA 18.55 m²/g Confirm
Solubility Insoluble in water Confirm
Available Quantities 25Gms, 50Gms, 100Gms and larger quantities
Main Inspect Verifier Manager QC (Tin Oxide Nanopowder)

Typical Chemical Analysis of Tin Oxide Nanopowder

As <2ppm
Cd <2ppm
Pb <32ppm
Ni <5ppm
Bi <9ppm
Zn <5ppm
Sb <7ppm
Al <2ppm
Cu <20ppm
Ag <2ppm
Fe <9ppm
In <8ppm

Experts Review:

58496396Dr. Bruce Perrault, Ph.D (Georgia Institute of Technology (Georgia Tech), USA)
Doping on nanomaterials provides a flexible way to tune to the properties of the materials while maintaining their high surface areas. The electronic, optical, photochemical, photo-electrochemical, photocatalytic and photoexcited relaxation properties can be tuned towards the desired direction by adding different elements. The materials can be engineered towards specific applications through careful selection of the dopants.


1252525Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)
Doping is a powerful and effective way to alter the electronic and optical properties of a semiconductor. Doping is essential in the semiconductor industry since most semiconductors including silicon are essentially insulators without doping at room temperature. The addition of dopant can introduce electronic and structural defects into the pristine nanomaterials that can be advantageous or deleterious.


2536582Dr. Huojin Chan (University of Science and Technology of China, Hefei, Anhui, China)
Doping typically follows a Poisson distribution. The uniform doping is done either by growth or nucleation techniques by decoupling the doping and growth process. In nucleation doping reaction conditions are controlled in such a way along with judicious choice of reactants that a nucleus of dopant can be created and by shell growth of effectively confining the dopant to the center of particle.


10604509_1459864657612760_2405225879143508610_oDr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
Nano-materials have been recently investigated due to their novel properties that are acquired at the nanometer scale, properties which change with size or shape. Besides the elemental composition and physical structure, as in bulk material or traditional chemistry, the size of the material provides another variable for us to tune the property of material. Moreover, a few dopants in the material can make the properties more adjustable.


125448Dr. Hans Roelofs Ph.D (National Technical University of Athens, Greece)
Dopant precursor substantially changes the reaction kinetics. Doped semiconductor nanomaterials are expected to play an important role in nanoelectronics and nanophotonic devices. Doping level of nanostructures will effects the properties and functionality of nanoparticles. Doped semiconductor nanomaterials constitute a unique and important class of nanomaterials with novel properties.


Tin Oxide Nanopowder

F-doped SnO2 Nanoparticles

This material ships as dry granules or powder. Each grade contains particles with an average thickness and surface area. All dimensions represent median sizes and there is a distribution around the mean. Tin Oxide Nanopowder by Nanoshel.
