Ultrapure SWCNT (Ultra Pure, 99.99%, Dia: <5nm, Avg Length: 20-30um)

High Purity Ultrapure SWCNT

Product: Ultrapure SWCNT  (Ultra Pure, 99.99%, Dia: <5nm, Avg Length: 20-30um)

Description: Sample purity of NANOSHEL Ultrapure SWCNT is 90-98 Vol%, as determined by Raman Spectrophotometer and SEM Analysis. Nanoshel Nano material contains no residual catalyst impurities. Tubes occur in bundles of length ~1 – 10μm. (±1.5μm) Individual tube length has not been determined.

FTIR Spectra Amine SWCNT

FTIR Spectra of Amine SWCNT

XPS Spectra Amine SWCNT

XPS Spectra of Amine SWCNT

Materials Single Walled Carbon Nanotubes (Ultrapure SWCNT )
Stock No. NS6130-06-697
CAS 308068-56-6
Diameter <5nm Confirm
Length 20-30µm Confirm
Purity >99.99% (SWCNT) Confirm
Amorphous carbon 1% Confirm
Residue (calcination in air) <1% Confirm
Special surface area 350-450* m2/g Confirm
Bulk density 0.05-0.17 g/cm3 Confirm
Real density 2-3 g/cm3 Confirm
Charging * 2180 (Capacity: mA h/g) Confirm
Discharging* 534 (Capacity: mA h/g) Confirm
Volume Resistivity 0.1-0.15 ohm.cm ( measured at pressure in powder) Confirm
Available Quantities 2Gms, 5Gms, 10Gms, 25Gms and larger quantites
Main Inspect Verifier Manager QC

Experts Review:

6386253Dr. Changsik Yoo, Ph.D (Nanyang Technological University, Singapore)
Ultrapure SWCNT for biomedical and biotechnological applications especially for their interesting use in the delivery of therapeutically active molecules to targeted cells. The interaction between cells and this nanomaterial is a critical feature that is responsible for the pharmacological effect as well as for any eventual toxicity. The latter aspect, in this manuscript evaluated a few parameters that seem to be involved in the cytotoxic profile of Ultrapure SWCNT and Multi-walled (MWCNTs) nanotubes), such as their sidewall functionalization, tubes’ length, solubility, concentration and purity. Ultrapure SWCNT totally dispersible, carbon nanotubes not only display lack of toxicity in the range of concentrations normally used (10-150 μg/ml), but they also pave the way for an extensive use of this material for several biomedical purposes.


12001Dr. Bram van Andel, Ph.D (International Medical and Technological University, Dar es Salaam, Tanzania)
Semiconducting Ultrapure SWCNT are promising materials for charge transport in field-effect transistor (FET) devices. In order to develop short channel s-SWCNT FETs with high on/off ratios relevant for logic applications, ultra-pure s-SWCNTs of 99.99999% semiconducting purity and higher are needed. The sorting of Ultrapure SWCNT, but most reports have only reached semiconducting purity levels near 99%. In addition, aligned arrays of Ultrapure SWCNT have the potential to improve the mobility and current output of FET. The purity and electronic transport properties of aligned arrays of polyfluorene-sorted s-SWCNTs in FET devices.


65562245Dr. Ana D. Gavrilovici (University of Santiago of Chile (USACH), Chile)
Ultrapure SWCNT are a natural choice as gas sensor components given their high surface to volume ratio, electronic properties and capability to mediate chemical reactions. However, a realistic assessment of the interaction of the tube wall and the adsorption processes during gas phase reactions has always been elusive. Making use of ultra-clean single-walled carbon nanotubes, we have followed the adsorption kinetics of NO$_2$ and found a physisorption mechanism.


10635845_949944621685989_4008592500456853568_nDr. Yeng-Tim Liu, (National Taiwan University of Science and Technology, Taiwan)
Ultrapure SWCNT is reflected in a production capacity that presently exceeds several thousand tons per year. Currently, bulk Ultrapure SWCNT powders are incorporated in diverse commercial products ranging from rechargeable batteries, automotive parts, and sporting goods to boat hulls and water filters. Advances in CNT synthesis, purification, and chemical modification are enabling integration of CNTs in thin-film electronics and large-area coatings. Although not yet providing compelling mechanical strength or electrical or thermal conductivities for many applications, CNT yarns and sheets already have promising performance for applications including supercapacitors, actuators, and lightweight electromagnetic shields.


2533854Dr. Sheng Choy Wong Ph.D (University of the Philippines College of Engineering, Quezon City, Philippines)
Ultrapure SWCNT unique combination of optical, thermal, mechanical, and electrical properties has led to substantial development activities in numerous applications such as composites, nanoelectronics, chemical and biosensors, and platforms for drug delivery.
The performance of Ultrapure SWCNT in each of these applications depends on the properties and purity of the SWCNT material. Variability in these materials can occur, depending on the manufacturing process used (e.g., chemical vapor deposition, laser ablation) and the conditions within a manufacturing run (e.g., temperature, catalyst concentration).


This material ships as dry granules or powder. Each grade contains particles with an average thickness and surface area. All dimensions represent median sizes and there is a distribution around the mean. Nanoshel offers Ultrapure SWCNT to Nanoparticles with wide variety of application and offers full scale projects for researchers. by Nanoshel.

Ultrapure SWCNT Banner

Ultrapure SWCNT



Contact Us for Ultrapure SWCNT
free quote

From us, you can easily purchase nano materials at great prices. Place online order and we will dispatch your order through DHL, FedEx, UPS. You can also request for a quote by mailing us at sales@nanoshel.com Contact: +1 302 268 6163 (US and Europe), Contact: +91-9779550077 (India). We invite you to contact us for further information about our company and our capabilities. At Nanoshel, we could be glad to be of service to you. We look forward to your suggestions and feedback.
