Ytterbium Trifluoride Nanopowder (YbF3, Purity: 99.9%)

Ytterbium Trifluoride Nanopowder

Product: Ytterbium Trifluoride Nanopowder (YbF3, Purity: 99.9%)

Quality Control: Each lot of Ytterbium Trifluoride Nanopowder was tested successfully.

Ytterbium Trifluoride

HRTEM of Ytterbium Trifluoride

Ytterbium Trifluoride

Size Analysis of Ytterbium Trifluoride

Product Name Ytterbium Trifluoride Nanopowder
Stock No NS6130-12-000288
CAS 13760-80-0 Confirm
APS 80-100 nm Confirm
Purity 99.9% Confirm
Appearance White Crystalline Powder Confirm
Chemical Formula YbF3 Confirm
Density 8.2 g/cm³ Confirm
Molecular Mass 230.04 g/mol Confirm
Crystallographic Structure Orthorhombic Confirm
Melting Point 1052 °C Confirm
Boiling Point 2380 °C Confirm
Solubility in Water insoluble Confirm
Available Quantities 25Gms, 50Gms, 100Gms and larger quantities
Main Inspect Verifier Manager QC

Typical Chemical Analysis

Composition Standard Test Result
La2O3 0.0005 % 0.0003 %
Y2O3 0.001 % 0.0008 %
CeO2 0.0005 % 0.0003 %
Pr6O11 0.0005 % 0.0003 %
Nd2O3 0.0005 % 0.0003 %
Sm2O3 0.0005 % 0.0003 %
Eu2O3 0.0005 % 0.0003 %
Gd2O3 0.0005 % 0.0003 %
Tb4O7 0.0005 % 0.0003 %
Fe2O3 0.0002 % 0.0001 %
Dy2O3 0.0005 % 0.0003 %
Ho2O3 0.0005 % 0.0003 %
Tm2O3 0.001 % 0.0007 %
Lu2O3 0.002 % 0.002 %

Experts Review:

58496396Dr. Bruce Perrault, Ph.D (Georgia Institute of Technology (Georgia Tech), USA)
Nanoparticles research has been providing innovative solutions in the field of biomedicine, cosmetics and electronics which may not have been possible by using the basic elements in their original states. This will elaborate on the properties and applications of Ytterbium Trifluoride nanoparticles. Ytterbium Trifluoride (YbF3) nanoparticles are a source of ytterbium that is insoluble in water. It is available in submicron, ultra high purity and nanopowder forms. The other names by which Ytterbium Trifluoride is known are ytterbium trifluoride and trifluoroytterbium.


1252525Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)
Ytterbium belongs to the F Block, Period 6 and fluorine belongs to Block P, Period 2 of the periodic table.
Safety information to be noted about these particles is that they are harmful if inhaled and if they come in contact with skin or eyes.


2536582Dr. Huojin Chan (University of Science and Technology of China, Hefei, Anhui, China)
Applications Some of the chief applications of Ytterbium Trifluoride are as below Production of metals as they have an affinity to oxygen Oil refining, pharmaceuticals and synthetic organic chemicals Alloying of metals ,Optical deposition ,Fiber optics, lasing and fiber amplifying applications, In silicon cells for the conversion of radiation to electricity.


10604509_1459864657612760_2405225879143508610_oDr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
Yttrium fluoride has been proposed as a substitute for thorium fluoride in anti-reflection coatings for the infrared range.
The ion assisted deposition (IAD) of YF3 in order to obtain dense and low absorbency layers in the 8 to 12 mm spectral window. Refractive index and extinction coefficient of this fluoride were determined from spectrophotometry measurements. We have then associated the YF3 with ZnS and Ge layers so as to obtain four layer anti-reflection coatings on germanium. The stress induced by each layer in the coating was measured and the sum was shown to be equal to the stress of the total coating. Eventually, an industrial, high efficiency, both side anti-reflection coating on germanium was developed using IAD YF3 film.


125448Dr. Hans Roelofs Ph.D (National Technical University of Athens, Greece)
Modified glassy carbon electrode with Ytterbium Trifluoride nanoparticles (YFNPs)-multiwalled carbon nanotubes (MWCNTs) was fabricated and then successfully used for the simultaneous determination of ascorbic acid (AA), dopamine (DA) and uric acid (UA).
YFNPs were successfully coated on the MWCNTs via the intermediate of noncovalent hydrophobic interactions of the MWCNTs surface with sodium dodecyl sulfate. The YFNPs and immobilization of YFNPs on MWCNTs were confirmed by transmission electron microscopy. The particle size of YFNPs was measured to be around 45 nm. The catalytic peak currents for AA, DA and UA were linearly dependent on their concentrations in the range of 2.0–600.0, 2.0–560.0 and 1.8–640.0 μM, respectively, with the corresponding detection limits of 0.77, 0.22 and 0.17 μM. The modified electrode provided good sensitivity and stability, and was successfully applied for the simultaneous determination of AA, DA and UA in human blood serum and urine samples.
