Home » Lithium Nickel Cobalt Manganese Oxide NCM532 (Li(Ni0.5Co0.3Mn0.2)O2, Purity: 99.9%, APS: 10microns)
LITHIUM ION BATTERY MATERIAL
| Stock No. | CAS | MSDS | Specification | COA |
|---|---|---|---|---|
| NS6130-12-001437 | 346417-97-8 |
|
|
|
Lithium Nickel Cobalt Manganese Oxide NCM532
(Li(Ni0.5Co0.3Mn0.2)O2, Purity: 99.9%, APS: 10microns)
SEM - NCM532
SEM - NCM532
Particles Size Analysis
| Product | Lithium Nickel Cobalt Manganese Oxide NCM532 | |
| Stock No | NS6130-12-001437 | |
| CAS | 346417-97-8 | |
| Purity | 99.9% | |
| APS | 10microns | |
| Molecular Formula | Li(Ni0.5Co0.3Mn0.2)O2 | |
| Appearance | Black Powder | |
| Melting Point | 290 °C (>554 °F) – lit. | |
| Boilling Point | 1342 °C (2448 °F) – lit. | |
| Cycle Life | 1000–2000 | |
| Flash Point | 26.1°C (79.0 °F | |
| Voltages | 3.60V, 3.70V nominal; | |
| Typical operating range | 3.0–4.2V/cell, or higher | |
| Specific energy (Capacity) | 150–220Wh/kg | |
| Charge (C-Rate) | 0.7–1C, charges to 4.20V, some go to 4.30V; 3h Charge Typical. Charge current above 1C shortens Battery | |
| Discharge (C-Rate) | 2.50V cut-off | |
| Thermal Runaway | 210°C (410°F) typical.High charge Promotes thermal runaway | |
| Application | E-bikes, medical devices, EVs, industrial | |
| Quality Control | Each lot of Lithium Nickel Cobalt Manganese Oxide NCM532 was tested successfully. | |
| Main Inspect Verifier | Manager QC | |
Typical Chemical Analysis
| Lithium % | 7.63% |
| Ni+Mn+Co | 58.36% |
| Impurities | . |
| Fe | 0.010% |
| Na | 0.0024% |
| Cu | ND |
| pH | 11.36 |
| Moisture | 350ppm |
| BET Surface Area | 0.239 m2/g |
| Tap Density | 2.62 g/cm3 |
| 1st Discharge Capacity | 153.6 mAH/g |
| 1st Efficiency | 86.96% |
Expert Reviews
Dr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
Space and military sectors use Lithium-ion batteries as portable power sources and in future, spacecraft like James Webb Space Telescope are expected to use lithium-ion batteries. The main reason for this rapid domination of lithium-ion battery technology in various sector is the highest storage capacity with respect to its weight.
Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)
Lithium-ion batteries are suitable for applications where both high energy density and power density are required, and they are superior to other types of rechargeable batteries such as lead-acid, nickel-cadmium, nickel-metal hydride etc. due to following aspects: (1) store more energy and deliver higher power for longer duration of time (2) get charged in shorter period of time (3) have a longer life time (4) be resistant to fire hazards.
Dr. Huojin Chan, (University of Science and Technology of China, Hefei, Anhui, China)
Now a days there is a great deal of interest to upgrade the exisiting LIBs with improved properties & a battery technology that would permit smart storage of electric energy.With the avident of next generation LIBs, electric vehicles are expected to cover longer distances with shorter charging time, mobile phones and laptops are expected to be charged within minutes and last longer.
Dr. Hans Roelofs, Ph.D (National Technical University of Athens, Greece)
Nanotechnology has the potential to deliver the next generation batteries, especially lithium-ion batteries, with improved performance, durability and safety at an acceptable cost. A typical lithium-ion battery consists of three main components: an anode made of (mainly graphene and other conductive additives), a cathode (generally a layered transition metal oxide) and electrolyte through which lithium ions shuttles between the cathode and anode during charging and discharging cycles.
Lithium Nickel Cobalt Manganese Oxide NCM532
From us, you can easily purchase Lithium Nickel Cobalt Manganese Oxide NCM532 at great prices. Place online order and we will dispatch your order through DHL, FedEx, UPS. You can also request for a quote by mailing us at sales@nanoshel.com. We invite you to contact us for further information about our company and our capabilities. At Nanoshel, we could be glad to be of service to you. We look forward to your suggestions and feedback.
