Home » Lithium Nickel Cobalt Manganese Oxide NCM622 (LiNiMnCoO2, Purity: 99.9%, APS: <400nm)

LITHIUM ION BATTERY MATERIAL

Stock No. CAS MSDS Specification COA Catalogue
NS6130-12-001210 346417-97-8 MSDS pdf Specification pdf COA pdf

Lithium Nickel Cobalt Manganese Oxide NCM622

(LiNiMnCoO2, Purity: 99.9%, APS: <400nm)

Available Pack Size: 10Gms, 25Gms, 50Gms, 100Gms, 250Gms, 500Gms, 1Kg & Bulk orders
SEM - NCM622

SEM - NCM622

SEM - NCM622

SEM - NCM622


Product Lithium Nickel Cobalt Manganese Oxide NCM622
Stock No NS6130-12-001210
CAS 346417-97-8
Purity 99.9%
APS <400nm
Molecular Formula LiNiMnCoO2
Appearance Black Powder
Melting Point 290 °C (>554 °F) – lit.
Boilling Point 1342 °C (2448 °F) – lit.
Cycle Life 1000–2000
Flash Point 26.1 °C (79.0 °F)
Voltages 3.60V, 3.70V nominal; typical operating range 3.0–4.2V/cell, or higher
Specific energy (Capacity) 150–220Wh/kg
Charge (C-Rate) 0.7–1C, charges to 4.20V, some go to 4.30V; 3h Charge Typical. Charge current above 1C shortens Battery life.
Discharge (C-Rate) 2.50V cut-off
Thermal Runaway 210 °C (410 °F) typical. High charge Promotes thermal runaway
Application E-bikes, Medical devices, EVs, Industrial
Quality Control Each lot of Lithium Nickel Cobalt Manganese Oxide NCM622 was tested successfully.
Main Inspect Verifier Manager QC

Typical Chemical Analysis

Lithium 7.2%
Ni+Mn+Co 59%
Impurities .
Fe <100ppm
Na <100ppm
Cu <150ppm
pH 11.7
Moisture 350ppm
BET Surface Area 0.35 m2/g
Tap Density 2.4 g/cm3
1st Discharge Capacity 181.5 mAH/g
1st Efficiency 89.6%

Expert Reviews

Dr. Bruce Perrault, Ph.D (Georgia Institute of Technology (Georgia Tech), USA)

Lithium–ion batteries seem to be everywhere these days. They power most of the electronic devices we carry around with us such as- Consumer Gadgets, Electric Cars, Cell phones, Digital cameras, MP3 Players, Laptops and so on. Due to their good energy-to-weight ratio, lithium batteries are some of the most energetic rechargeable batteries available today. They get their name from lithium ion that moves from the anode to the cathode during discharge and from cathode to anode during recharging.


Dr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)

Space and military sectors use Lithium-ion batteries as portable power sources and in future, spacecraft like James Webb Space Telescope are expected to use lithium-ion batteries. The main reason for this rapid domination of lithium-ion battery technology in various sector is the highest storage capacity with respect to its weight.


Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)

Lithium-ion batteries are suitable for applications where both high energy density and power density are required, and they are superior to other types of rechargeable batteries such as lead-acid, nickel-cadmium, nickel-metal hydride etc. due to following aspects: (1) store more energy and deliver higher power for longer duration of time (2) get charged in shorter period of time (3) have a longer life time (4) be resistant to fire hazards.


Dr. Huojin Chan, (University of Science and Technology of China, Hefei, Anhui, China)

Now a days there is a great deal of interest to upgrade the exisiting LIBs with improved properties & a battery technology that would permit smart storage of electric energy.With the avident of next generation LIBs, electric vehicles are expected to cover longer distances with shorter charging time, mobile phones and laptops are expected to be charged within minutes and last longer.


Dr. Hans Roelofs, Ph.D (National Technical University of Athens, Greece)

Nanotechnology has the potential to deliver the next generation batteries, especially lithium-ion batteries, with improved performance, durability and safety at an acceptable cost. A typical lithium-ion battery consists of three main components: an anode made of (mainly graphene and other conductive additives), a cathode (generally a layered transition metal oxide) and electrolyte through which lithium ions shuttles between the cathode and anode during charging and discharging cycles.


Lithium Nickel Cobalt Manganese Oxide Nanopowder

Lithium Nickel Cobalt Manganese Oxide Nanopowder
