Vanadium Nitride Nanopowder (VN, Purity: 99.9%, APS: 80-100nm)

Nano Powder – Vanadium Nitride Nanopowder

Product: Vanadium Nitride Nanopowder  (VN, Purity: 99.9%, APS: 80-100nm)

Quality Control: Each lot of NANOSHEL Vanadium Nitride Nanopowder was tested successfully.

Product Name Vanadium Nitride Nanopowder
Stock No. NS6130-12-000387
CAS 24646-85-3 Confirm
Appearance Black Powder Confirm
APS 80-100nm Confirm
Molecular Formula VN Confirm
Purity 99.9% Confirm
Density 6.13 g/mL Confirm
Molecular Weight 64.95 g/mol Confirm
Crystallographic Structure Cubic Confirm
Melting Point 2050 °C Confirm
Available Quantities 25Gms, 50Gms, 100Gms and larger quantities
Main Inspect Verifier Manager QC

Typical Chemical Analysis

Assay 99.5 %
Fe 0.1 %
Si 0.05 %
O 0.1 %
N 0.2 %
Na 0.01 %
K 0.005 %
Ca 0.01 %

Experts Review:

58496396Dr. Bruce Perrault, Ph.D (Georgia Institute of Technology (Georgia Tech), USA)
Ultra-High Temperature Ceramics are a family of compounds that display a unique set of properties, including extremely high melting temperatures (> 3000°C), high hardness, and good chemical stability and strength at high temperatures. Structural materials for use in high-temperature oxidizing environments are presently limited mostly to SiC, Si3N4, oxide ceramics, and composites of these materials.


1252525Dr. Myron Rubenstein, Ph.D (Polytechnic University of Turin, Italy)
UHTC materials are typically considered to be the carbides, nitrides, and borides of the transition metals, but the Group IV-V compounds (Ti, Zr, Hf, Ta) due to the superior melting temperatures and formation of stable high-melting temperature oxides. The combination of properties make these materials potential candidates for a variety of high temperature structural applications, including engines, hypersonic vehicles, plasma arc electrodes, cutting tools, furnace elements, and high temperature shielding.


2536582Dr. Huojin Chan (University of Science and Technology of China, Hefei, Anhui, China)
Boride ceramics offer an unusual combination of ceramic-like properties including high melting temperature (>3000°C), elastic modulus (~500 GPa), and hardness (>20 GPa) with metallic characteristics such as high electrical conductivity (~107 S/m) and thermal conductivity (60-120 W/m•K). This combination of properties makes UHTCs attractive for applications such as the leading edges of hypersonic aerospace vehicles and atmospheric re-entry vehicles, which require materials to retain their shape at temperatures in excess of 2000°C.


10604509_1459864657612760_2405225879143508610_oDr. Ms. Yi Yen Shi, (King Mongkut’s University of Technology Thonburi,Bangkok, Thailand)
UHTCs all exhibit strong covalent bonding which gives them structural stability at high temperatures. Metal carbides are brittle due to the strong bonds that exist between carbon atoms. The largest class of carbides, including Hf, Zr, Ti and Ta carbides have high melting points due to covalent carbon networks although carbon vacancies often exist in these materials; indeed, HfC has one of the highest melting points of any material. Nitrides such as ZrN and HfN have similarly strong covalent bonds but their refractory nature makes them especially difficult to synthesize and process.


125448Dr. Hans Roelofs Ph.D (National Technical University of Athens, Greece)
The development of ultra-high temperature ceramics for aerospace applications continues around the globe. Development is likely to be driven by “market pull” based on applications where performance requirements necessitate the use of ceramics due to some combination of temperature requirements, weight savings compared to heavier refractory metals, or use of simpler passive designs as opposed to more complex actively cooled components.


Vanadium Nitride Nanopowder Banner

Vanadium Nitride Nanopowder

free quote

Contact Us for Vanadium Nitride Nanopowder
From us, you can easily purchase Vanadium Nitride Nanopowder at great prices. Place online order and we will dispatch your order through DHL, FedEx, UPS. You can also request for a quote by mailing us at sales@nanoshel.com Contact: +1 302 268 6163 (US and Europe), Contact: +91-9779550077 (India). We invite you to contact us for further information about our company and our capabilities. At Nanoshel, we could be glad to be of service to you. We look forward to your suggestions and feedback.
