Silicon Nanowire on Silicon Wafer Substrate (Si, >99.9%, Diameter: 40-50nm, Length: 80µm) [Currently Not Available]

Silicon Nanowire on Silicon Wafer Substrate (Currently Not Available)

Product: Silicon Nanowire on Silicon Wafer Substrate (Si, >99.9%, Diameter: 40-50nm, Length: 80µm)

Quality Control: Each lot of NANOSHEL Silicon Nanowire on Silicon Wafer Substrate was tested successfully.

SEM - Silicon Nanowire on Silicon Wafer Substrate

SEM - Silicon Nanowire on Silicon Wafer Substrate


Product Name Silicon Nanowire on Silicon Wafer Substrate
Stock No NS6130-12-000158
CAS 7440-21-3 Confirm
Purity >99.9% Confirm
Diameter 40-50nm Confirm
Length 80µm Confirm
Molecular Formula Si Confirm
Form Wire Confirm
Color Gray Suspension color Confirm
Concentration 1 - 2 % Confirm
pH 7.9-8.1 Confirm
Coefficient of Variation 51% Confirm
Standard Deviation 10% Confirm
Iso- propanol 0.5% Confirm
Polymer Content < 0.5% Confirm
Solvet Ethanol, Water, Isopropyl Alcohol
Main Inspect Verifier Manager QC

Typical Chemical Analysis

Assay >99.9%
Other Metal 1000 ppm
